TURBO PSK RECEIVER WITH 4-PORT SWITCH OPTION
RF SWITCH INPUT
4-port, single-throw switch
Input Impedance
75
Ω unbalanced
Isolation, port-to-port
> 45 dB, 950-1450 MHz
> 40 dB, 1450-2150 MHz
Input VSWR, 75-
Ω system, selected port
< 1.9:1 (10 dB R.L. min), 950-1450 MHz
< 1.9:1 (10 dB R.L. min), 1450-2150 MHz
Input VSWR, 75-
Ω system, unselected port < 1.9:1 (10 dB R.L. min), 950-1450 MHz
< 1.9:1 (10 dB R.L. min), 1450-2150 MHz
Surge Resistance
Guaranteed survival from up to 10 direct-coupled 8kV
discharges (per IEC 801-2) whether or not port is selected
RF TUNING
Same as Turbo PSK option described (above)
DEMODULATOR/FEC
Same as Turbo PSK option described (above)
LNB DC POWER
Supplied on RF Input Port 4 - same electrical characteristics as
described for single-input Turbo PSK option (above)
ASI TRANSPORT INPUT OPTION
DVB-ASI INPUT
One input per DVB ASI per EN50083-9 Annex B
Physical layer
270 Mbaud signaling on 75
Ω coax cable
Minimum byte gaps
Down to 0-byte interbyte gaps
Transport data rate
Limited to rates allowed by parent IRD
Characteristic
Specification
