5
INSTALLER/CONFIGURATION MENU
To enter the menu: Press the Menu touch key . Press and hold for 5 seconds the Installer Config touch key . This displays
menu item #1 in the table below . Press to advance to the next menu item or to return to a previous menu item . Press
or to change a menu item .
Installer Note: To default the programming, clock and Configuration Menu to the Factory Default Settings, press the ,
and SYSTEM keys simultaneously . The thermostat display will go blank for a few seconds, and then all segments will display
momentarily .
CONFIGURATION MENU
Menu
Reference
Number
Program-
mable
Non-
Program-
mable
Press
Button
Displayed
(Factory
Default)
Press or to
select from listed
options Comments
1 1 1 (ELE) GAS GAS setting: furnace controls blower
ELE setting: thermostat controls blower
2 2 2 Days, (7) P 5-1-1 or 0 Programs per week . (0 = non-programmable)
3 3 NA PS (4) 2 Program periods per day
4 = Morning, Day, Evening, Night
2 = Day, Night
4 4 3 Cool-Off-
Heat-Auto
Cool-Off-Heat,
Off-Heat, Cool-Off
System switch configuration
5 5 NA E (On) OFF Selects Energy Management Recovery, E (with programming
option on)
6 6 4 Cr, Heat (FA) SL Selects Adjustable Anticipation, cycle rate, Heat
7 7 5 Cr, Cool (FA) SL Selects Adjustable Anticipation, cycle rate, Cool
8 8 6 CL (OFF) On Selects Compressor Lockout
9 9 7 dL (On) OFF Selects Continuous Display backlight & intensity
10 10 8 dL (LO) HI Selects Backlight Intensity
11 11 9 0 4, LO to 4, HI Selects Adjustable Ambient Temperature Display [range -4 (LO)
to +4 (HI)]
12 12 10 °F °C Selects °F/°C Display (temperature units in Fahrenheit or Celsius)
13 13 11 b (On) OFF Selects audible Beeper On/Off
14 14 12 dS (On) OFF Selects Daylight Saving Time calculation
15 15 13 AS, Heat (On) OFF Selects Automatic Schedule for comfort temperature
Programming, heat mode
16 16 14 AS, Cool (On) OFF Selects Automatic Schedule for comfort temperature
Programming, cool mode
17 17 15 CS, (OFF)
Cool Savings
1-2-3-4-5-6 Selects Cool Saving Feature & amount
18 18 16 HL, Heat (99) 62-98 TEMPERATURE LIMIT, HEAT (max . heat set point)
19 19 17 LL, Cool (45) 46-82 TEMPERATURE LIMIT, COOL (min . cool set point)
20 20 18 OFF,
Keypad Lockout
L (total), P (partial),
Temperature Limit
(limited temperature range)
Selects Keypad Lockout
000 001-999 Selects Keypad Lockout Combination (active only if keypad
Lockout is selected)
21 21 19 Remote (OFF) On Remote temperature sensor, enable/disable
In, Remote Outdoor Remote Remote temperature sensor (Indoor/Outdoor)
LS (On) OFF Local temp . Sensor enable/disable (only when Indoor Remote is
selected On)
22 22 20 Change Filter
(OFF)
On Selects Change filter feature
200 Hours 25-1975 (in increments
of 25 hours)
Change filter, duration hours
