VACUUM SHOE ASSEMBLY
CADET 86038220 03/16/07
5-10
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86227350 05016 4 ARM, VAC SHOE PARALLEL
2 86234760 27674 1 COVER, ACCESSORY PORT
3 86005810 57245 4 NUT, 1/4-20 HEX NYLOCK SS
4 86006790 70351 2 SCR, 10-32 X 3/8 HHTR W/STAR
5 86275120 70360 4 SCR, 1/4-20 X.75 PPHMS PHIL
6 86006840 70390 4 SCR, 1/4-20 X 1 FHCS PLTD
7 86008130 73958 8 SPACER, 3/8ODX.058WX.2814,CRS
8 86010620 85039 1 VAC SHOE, 15"
9 OPEN - -
10 86010630 87013 4 WASHER, 1/4 ID X 5/8 OD SS
11 86010700 87074 8 WASHER, WAVE 3/8ID X3/4D X.125
12 86003780 35171 1 GASKET, ACCESSORY PORT
13 86008120 73955 2 SPRING, EXT .38D X2.75L X.055W
