Model 693 – White Outdoor 693 User Manual
Page 29
29
Model 693
REF.
NO.
PART NO.
DESCRIPTION
1
732-0750A
Spring Switch
2
712-0265
Hex Sems Nut 5/16-18 Thd.
4
731-1734
Index Bracket
5
710-0924
Pan Hd. Mach. Scr. 1/4-20 x .75" Lg.
6
710-0599
Hex Washer TT-Tap Scr. 1/4-20 x .5"
7
712-0138
Hex Nut 1/4-28 Thd.
8
736-0329
L-Wash. 1/4" I.D.*
10
710-0642
Hex. Bolt 1/4-20 x .75" Lg.
11
783-0310C
Lower Frame Ass’y.
14
725-1426
Solenoid
15
736-0222
Ext. L-Wash. 1/4" I.D.
17
750-0956
Spacer
18
756-0983
Engine Pulley
19
711-1044
Belt Guard Stud 4.75" Lg.
20
736-0322
Fl-Wash. 7/16" I.D. x 1.25" O.D.
21
736-0171
L-Wash. 7/16" I.D.*
22
710-3029
Hex Bolt 7/16-20 x 1.25" Lg.
23
735-0196
Foot Pad
24
683-0049
Brake Lockout Brkt. Ass’y.
26
732-0728
Foot Pedal Return Spring
27
738-0296
Shld. Bolt .437" Dia. x .268"
28
736-0406
Fl-Wash. 7/16" I.D. x 1-3/8" O.D.
29
747-0608A
Lock-up Rod
30
17755A
Bracket
31
736-0119
L-Wash. 5/16" I.D.*
32
712-3010
Hex Nut 5/16-18 Thd.*
33
720-0166
Ball Knob
34
732-0727
Neutral Return Spring
35
712-0273
Hex Nut 5/16-24 Thd.
36
736-3078
Fl-Wash. .565 I.D. x 1.12 O.D. x .06
37
783-0092
Scissor-Flat
38
736-0414
Fl-Wash. .33" I.D. x 1.25" O.D.
39
750-0808
Spacer
40
736-0219
Bell-Wash. .4" I.D. x 1.13" O.D.
41
761-0196
Friction Washer
42
750-0918
Centering Gauge Spacer
43
783-0095
Neutral Return Mtg. Brkt.
44
736-0270
Bell-Wash. .265" I.D. x .75" O.D.
45
732-0718
Comp. Spring 1.19" Lg.
46
736-3008
Fl-Washer .344 I.D. x .750 O.D. X .120
47
712-3057
Hex Nut 5/16-24 Thd.
48
710-0299
Hex Bolt 1/4-28 x 1" Lg. (Gr. 5)
49
710-1012
Rib Neck Bolt 5/16-24 x .84" Lg.
50
783-0093
Scissor-Offset
51
747-0887
Neutral Return Rod
52
738-0879
Friction Disc Stud
53
748-0368
Shld. Spacer
54
783-0096
Neutral Return Lever
55
736-3092
Fl-Wash. .265" I.D. x 1" O.D.
56
736-0329
L-Wash. 1/4" I.D.*
57
712-0271
Hex Nut 1/4-20 Thd.*
58
714-0104
Hairpin Clip
59
736-0185
Fl-Washer .406" I.D. x .750" O.D. X .63
60
736-0413
Spring Wash. .39" I.D.
61
712-0116
Hex L-Nut 3/8-24 Thd.
62
712-0711
Hex Jam Nut 3/8-24 Thd.
63
783-0090A
Neutral Return Brkt.
64
711-0832
Ferrule 3/8-24 Thd.
65
747-0365
Control Rod
66
723-0351
Ball Joint 3/8-24 Thd.
67
748-0234
Shld. Spacer .5" Dia. x .27" Lg.
68
736-0159
Fl-Wash. .349" I.D. x .879" O.D.
69
710-1189
Hex Tap Scr. #12 x 24 x .82 Lg.
70
731-1449
Fan
71
712-0333
Hex Nut 1/2-20 Thd.
72
736-0921
L-Wash. 1/2" I.D.*
73
712-0241
Hex Nut 3/8-24 Thd.
74
736-0169
L-Wash. 3/8" I.D.
75
756-0975
Transmission Pulley
76
732-0729
Wire Ring
77
754-0441
“V”-Belt
78
756-0981
Fl-Idler Pulley 2.75" O.D.
79
720-0238
Rod End Grip
80
747-0894
Bypass Control Lever
81
783-0085
Transaxle Support Brkt.–L.H.
82
710-0528
Hex Bolt 5/16-18 x 1.25" Lg.
83
732-0384
Ext. Spring 6.12
84
683-0051
Idler Brkt. Ass’y.
85
710-0395
Hex Bolt 5/16-18 x 2.25" Lg.*
86
710-0376
Hex Bolt 5/16-18 x 1.00" Lg.*
87
748-0234
Shld. Spacer .5" Dia. x .27" Lg.
88
783-0086A
Transaxle Support Brkt.–R.H.
89
747-0886
Brake Rod 24.94" Lg.
90
732-0716
Ext. Spring
91
747-0893
Bypass Actuator Rod
92
736-0142
Fl-Wash. .281" I.D. x .5" O.D.
93
783-0098
Bypass Adjustment Brkt.
94
736-0222
External L-Wash. 1/4" I.D.
95
731-1086A
Sleeve .758" I.D. x 1" O.D.
96
710-0604A
Hex. TT-Tap Scr. 5/16-18 x .62"
97
17994
Retainer Brkt.-Transaxle
98
710-0176
Hex Bolt 5/16-18 x 2.75" Lg.
100 710-0888
Hex Bolt 5/16-24 x 1" Lg. (Special)
101 710-0224
Hex Wash. Hd. AB-Tap Scr. #10 x .5" Lg.
107 647-0008A
Speed Control Lever Ass’y.
108 17668
Axle Support Brkt.–R.H.
17669
Axle Support Brkt.–L.H. (Not
Shown)
109 732-0433
Ext. Spring 2.75" Lg.
110 736-0141
Spr-Wash. .445" I.D. x .75" O.D.
111 17840
Transaxle Mtg. Brkt.
112 725-1657A
Safety Switch (Clutch)
115 710-1238
Hex Hd. Wash. 5/16-18 x .875"
116 683-0123
Clutch/Brake Pedal Ass’y.
117 750-0802
Spacer .63" I.D.
118 17860
Pedal Bracket
119 736-3008
Fl-Wash. .344" I.D. x .75" O.D.
120 714-0111
Cotter Pin 3/32" Dia.
121 714-0470
Cotter Pin 1/8" Dia.
122 736-0140
Fl-Wash. .385" I.D. x .62" O.D.
123 710-0227
Hex AB-Tap Scr. #8 x .5" Lg.
124 726-0320
Insulator Nut Plate
125 725-1713
Spring Switch
126 725-1399
Extension Wire
127 710-0520
Hex Bolt 3/8-16 x 1.5" Lg.
REF.
NO.
PART NO.
DESCRIPTION
