Operator’s manual, Front tine tiller, Model 393

Front Tine Tiller
Model 393
OPERATOR’S MANUAL
IMPORTANT: READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Warning:
This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-
covered, brush-covered or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting
applicable local or state laws (if any). If a spark arrester is used, it should be maintained in effective working order by the operator.
In the State of California the above is required by law (Section 4442 of the California Public Resources Code). Other states may have
similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized
service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-0019.
PRINTED IN U.S.A.
FORM NO.
770-10135D.fm
(10/04)
Document Outline
- NOTE: References to right or left side of the tiller are determined from behind the unit in the operating position.
- NOTE: Do not overtighten control cable. Too much tension may cause it to break when engaged.
- NOTE: Never engage both the forward and reverse tine drives at the same time. Engaging both forward and reverse tine drives at the same time could damage the belt drives and cause the engine to stall.
- NOTE: Be careful not to burn your hand on the muffler when engaging and disengaging the choke. The muffler is located above the choke and will be very hot after the motor has been running just a short period of time.
- NOTE: When storing any type of power equipment in an unventilated or metal storage shed, care should be taken to rustproof the equipment. Using a light oil or silicone, coat the equipment and especially any springs, bearings, and cables.
