Inside Federal Corners
Flash the corner with aluminum trim coil or other flashing
materials.
Position and secure the 5" lineals (or a 3-1/2" lineal) by butting
the lineal up to the inside corner. Using a 5" lineal will create a
symmetric 3-1/2" exposure in the corner. If two 3-1/2" lineals
are used, one exposure will be approximately 2-1/4" and one
will be 3-1/2".
NOTE: Attaching the second lineal will keep the first lineal
in place. You will not need a starter strip. Always position
the top nail in the top of the nailing slot. All other nails
should be centered in the slots spaced 8" to 10" apart.
Position and secure the starter strip.
Position and secure the remaining lineal.
“L” shaped
flashing
