Wolverine Siding and Vinyl Carpentry Soffit and Decorative Trim - Manual (Page 13)

3/8" H-bar
1/2" H-bar
Joins soffit panels. Particularly useful on porch ceilings and hip
roof applications.
3-1/2" Double Channel Lineal
5" Double Channel Lineal
Exposure matches 3-1/2" window and door surround lineals.
Lineal Options
3-1/2" Lineal
For use with a New Construction Window and Door Starter
around windows and doors as a casing. The 3/4" channel
receives siding panels. Can also be used as a cornerpost.
3-1/2" Snap-on Lineal
For use with J-channel.
5" Lineal
Two lineals create a corner system when installed with a
Corner Starter and corner insert. Can also be used with a
window starter strip as a window/door casing. The 3/4"
channel receives siding panels.
Quarter Round Insert
Installed with a Corner Starter and lineals as a decorative
corner treatment.
Drip Clip ™
Use to create a rain tab on lineals.
12
Wolverine Fit and Finish Installation Guide
