13. Attach the Leg Press Attachments (100) to the Rear
and Forward Leg Press Uprights (97, 98) with two
3/8Ó x 3Ó Bolts (45) and two 3/8Ó Nylon Jam Nuts (63).
13
45
100
100
98
12. Attach the Rear and Forward Leg Press Uprights (97,
98) to the Leg Press Base (84) with two 3/8Ó x 3 1/4Ó
Bolts (87) and two 3/8Ó Nylon Locknuts (50). Note:
The Rear Leg Press Upright (97) has an extra hole
in it.
Press two 2Ó Square Inner Caps (33) into the Rear
and Forward Leg Press Uprights (97, 98).
33
63
97
12
14. Attach the Leg Press Plate (85) to the Leg Press
Attachments (100) with two 3/8Ó x 3 1/4Ó Bolts (87),
eight 3/8Ó Flat Washers (55), and two 3/8Ó Nylon Jam
Nuts (63).
Note: All of the eight 3/8Ó Flat Washers (55) must
be between the Leg Press Attachments (100) and
the welded tube on the Leg Press Plate (85).
14
85
100
87
55
55 Welded
Tube 63
