9
Set Current Time and Date
1) Press Menu and then Time button once. The display
will show the hour only.
2) Press and hold either the or button until you
reach the correct hour and AM/PM designation (AM
begins at midnight, PM begins at noon).
3) Press TIME once again. The display window will show
the minutes only.
4) Press and hold either the or button until you
reach the correct minutes.
5) Additional presses of TIME will advance the display to
show the year, month and date of month. Press the
or
button to change the display to the correct set-
ting for each.
6) Press RUN to exit the TIME mode.
PROGRAMMING
The programmable thermostats are programmed with the energy saving settings shown in the table below for all days of the
week. If this program suits your needs, simply set the thermostat clock and press the RUN button. The table below shows the
factory set heating and cooling schedule for all days of the week.
Wake Up
(Period 1)
Leave For Work
(Period 2)
Return Home
(Period 3)
Go To Bed
(Period 4)
Heating
Program
6:00 AM 70°F 8:00 AM 62°F 5:00 PM 70°F 10:00 PM 62°F
Cooling
Program
6:00 AM 75°F 8:00 AM 83°F 5:00 PM 75°F 10:00 PM 78°F
Planning Your Program – Important
The Heating and Cooling Program schedules below allow you
to pencil in your own program times and temperatures.
The thermostat comes configured for 7 day programming
and can also be configured for 5/1/1 day programming (see
configuration section).
Factory settings are listed on Monday through Friday, Satur-
day and Sunday. If you are re-programming a 7 day schedule,
pencil in all lines with the times and temperatures you want.
If you are re-programming a 5+1+1 fill in your own times and
temperatures directly below the factory times and tempera-
tures.
Keep the following guidelines in mind when planning your
program.
• In Heating, lower temperatures will save energy.
• In Cooling, higher temperatures will save energy.
• If you plan on using Auto Changeover, do not program
the heating higher than the cooling.
Energy Saving ENERGY STAR ® Factory Pre-Program
Enter the Heating Program
1) Press SYSTEM button to select “Heat” in the system
switch area indicating the active mode being pro-
grammed.
2) Press the MENU button and then press SCHEDULE.
3) The top of the display will show the day(s) being pro-
grammed. The time and temperature (flashing) are also
displayed. “1” will also be displayed to indicate the period.
4) Press or button to change the temperature to
your selected temperature for the 1st heating period.
5) Press TIME button, time will flash.
6) Press
or button to adjust the start time for the
1st period.
7) The time will change in 15 minute increments.
8) After you have set the time and the temperature for
the period to begin, press SCHEDULE to advance to the
next program period.
9) Repeat steps 2 through 8 until all of the program times
and temperatures are set for all program periods on
that day.
10) Press SCHEDULE to the next day and repeat steps 2
through 9.
11) When programming is complete and all of the times and
temperatures match your desired heating schedule, press
RUN. The thermostat will now run your program.
Enter the Cooling Program
1) Press SYSTEM button to select “Cool” in the system
switch area indicating the active mode being pro-
grammed.
2) Follow Enter Heating Program instructions for entering
cooling times and temperatures.
