6.
7.
a.
9.
Lower machine to floor. Dispense
solution by using either the continuous
pump switch or the intermittent pump
switch. Use the continues pump switch
for large open areas. Use the intermittent
pump switch for small confined areas.
Walking backwards, move the extractor
over the area to be cleaned. The ex-
tractor’s brush assistance allows the
machine to moved quickly and easily
over the carpet. Remember to turn off
the pump switch about six inches before
the end of each pass.
As you work check for foam building up in
the recovery tank. If foam is building up
stop and add the recommended amount
of defoaming compound to the recovery
tank.
Never put defoaming compound in
the solution tank!
WARNING:
An overflow of foam from the recovery
tank into the vacuum intake can damage
the vacuum motor. Always be aware of
the waste water level in the recovery
tank. When the tank is about three
quarters full, turn off the machine, bring
the machine to a floor drain, and drain the
recovery tank using the convenient drain
hose located at the rear left corner of the
tank.
As the extractor begins to run out of
cleaning solution it will start streaking and
won’t completely clean the carpet. When
the extractor runs out of cleaning solution
turn off the machine, drain the recovery
tank as described above, remove the
dome and recovery tank, and refill the
clean solution tank.
Ventilate the area which has been
cleaned. Keep children and pets away
and prohibit traffic until carpet is
completely dry.
6
To Use an Accessory Tool:
1. Turn the machine completely off and
unplug it from electrical outlet.
2. Turn solution valve to “Accessory Tool
Position”.
3. Remove recovery hose (white cuff) from
dome and insert hose from accessory
tool in its place.
4. Attach solution hose from accessory tool
to the “Accessory Tool Solution
Connection” located on the upper right
back of the chassis.
5. Make sure the solution tank has solution
and that the recovery dome and tank are
in place and ready for operation.
6. Plug the machine in and turn on only the
vac/pump switch.
CAUTION:
Using accessory tool with brush switch
on may damage floor
7. Make sure the solution valve is returned
to the “Carpet Spray Position” before
returning the ADP to standard carpet
extraction.
6. Turn off the machine and unplug it from
electrical outlet before disconnecting
accessory tool.
Approved Accessory Tools:
Standard Floor Wands
(SFW, SW, or SW-PRO)
Deluxe Hand Tool
Upholstery Hand Tool (UPH3)
