GROUT HOG ASSEMBLY
GROUTHOG 86038000 05/17/07 9
REF PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86278140 70002 SHOULDER BOLT, 3/8 OD X 2.0 L
2 86259660 89038 WHEEL, GH 4" DIA.
3 86010680 87030 WASHER, 3/8 ID X 3/4 OD NYLON
4 86278910 87003 WASHER, 3/8 ID X 7/8 OD SS
5 86005750 57113 NUT, 5/16-18 HEX NYLOCK
6 86274050 70078 SCR, 5/16 X 3/8 PHSB PH SS DL
7 86091970 14222 BRKT ASM, GH HANDLE ADJ.
8 - OPEN -
9 86226780 73044 SPRING, EXT .44 D X 2.25 L X .054 W
10 86005720 57106 NUT, 1/4-20 HEX NYLOCK
11 76006490 70013 SCR, 8-32 X 3/4 PHMS SS
12 86273920 70049 SCR, 1/4-20 X 1.75 PHMS SS
13 86264220 66059 PLUG, GH HANDLE PIVOT
14 86005680 57047 NUT, 1/4-20 HEX NYLOCK
15 86273740 70010 SCR, 1/4-20 X 1.5 HHCS SS
16 86093390 66058 PIVOT, GH HANDLE
17 86010630 87013 WASHER, 1/4 ID X 5/8 OD SS
18 86010660 87025 WASHER, 1/4 LOCK EXT STAR SS
19 86273830 70020 SCR, 1/4-20 X 1/2 HHCS SS DL
20 86028070 48013 KNOB ASM, GH BEARING BLOCK
21 86028470 73183 SHIELD ASM, GH3 SPLASH
22 86010690 87068 WASHER, 1/8 RIVET BACKUP
23 86233060 20001 CLAMP, BAG SUPPORT
24 86086930 73157 SHIELD, GH SPLASH
25 86086340 67063 ROD, GH SPLASH SHLD HANGER
26 86086330 67062 ROD, GH SPLASH SHLD ROLLER
27 86264380 67061 ROLLER, SPLASH SHIELD
28 86273070 67005 RIVET, 1/8 OD WHT AL
29 86027310 14215 BLOCK ASM, GH LH BEARING
30 86272180 66060 PIN, ROLL 1/4" X 3/4" L
31 86228560 09021 BEARING, GH BRUSH SHAFT
32 86094050 73161 SHAFT/HUB ASM, GH DRIVEN
33A 86283940 12019 BRUSH, GH UNIVERSAL STANDARD
33B 86283950 14248 BRUSH, GH ALL PURPOSE AGGRESSOR
34 86064140 36045 GUARD, GH3 BELT
35 86006650 70177 SCR, 10-32 X 1/2 FHMS SS
36 - OPEN -
37 86094060 73163 SHAFT/HUB ASM, GH BRUSH DRIVE
38 86027320 14216 BLOCK ASM, GH RH BEARING
39 86277940 70126 SET SCR, 1/4-28 X 1/4 KCP
40 86250440 64029 PULLEY, GH BRUSH 20L050
41 86007670 73166 SNAP RING, EXTERNAL
42 86090230 87015 WASHER, 9/16 ID X 1.06 OD SS
43 86197300 14079 BUSHING, 1/8 FPT X 1/4 MPT HEX
44 86273780 70015 SCR, 1/4-20 X 3/4 HHCS SS
45 86226390 27218 CAP, GH FRAME TUBE
46 86273860 70025 SCR, 10-32 X 3/4 IHHMS UN SL SS
47 86273930 70051 SCR, 8-32 X 1/2 PPHMS
48 86005700 57104 NUT, 10-32 W/STAR WASHER PLTD
