GROUT HOG ASSEMBLY
GROUTHOG 86038000 05/17/07
10
REF PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
49 86092320 34111 FRAME, GH3 MAIN
50 86090390 89037 WEIGHT, GROUT HOG COUNTERBALANCE
51 86251350 67064 RELAY, 120V SPDT
52 86197560 40015 HOSEBARB, 1/4 FPT X 3/8
53 86237150 35065 GASKET, GH3 COVER
54 86076200 36051 GUSSET, GH3
55 86279090 87067 WASHER, 5/16 LOCK INT. STAR PLT
56 86277940 70126 SET SCR, 1/4-28 X 1/4 KCP DL
57 86229270 11011 BELT, GH3 DRIVE
58 86250430 64028 PULLEY, GH MOTOR 10L050
59 86271110 57123 NUT, 1/4-20 CAPTIVE (.074 W)
60 86247080 53113 MOTOR, 115V 1/3 HP W/T.O.
61 86274160 70110 SCR, 10-24 X 3/4 PHTC -F-
62 86244960 50211 LABEL, GROUTHOG MAIN
63 86256610 72015 SWITCH, SPDT 20A SNAP-ACTION
64 86279110 87075 WASHER, 3/8 ID INT. LOCK
65 86005670 57040 NUT, 1/2 NPT CONDUIT
66 86244990 50228 LABEL, GH WARNING
67 86244970 50212 LABEL, GROUTHOG ON
68 - OPEN -
69 86234710 27237 COVER, SWITCH PROTECTIVE
70 86245160 50399 LABEL, L1500 WARNING
71 86256200 73200 STRAIN RELIEF, 1/2 NPT FLEX
72 86244980 50213 LABEL, GROUTHOG OFF
73 86063380 27230 COVER, GH3 BLUE
74 86245260 50490 LABEL, 115V GH3 WIRING
75 86234100 23075 CORD ASM, 18/3 X 40 SJT, YL GH3
76 86006800 70361 SCR, 10-32 X 1/2 PHTR PLT
77 86076740 41144 HOOK, CORD
78 86256170 73169 STRAIN RELIEF, CORD HOOK
79 86092630 38079 HANDLE, GH MAIN
80 86232340 50352 CARD, GH3 INSTRUCTION
81 86245650 50776 LABEL, FOR SAFETY
