TECHNICAL SPECIFICATIONS
CUTTER 24V 86039080 04/17/07
3-1
ITEM DIMENSION/CAPACITY
Nominal power
1450 W
Rated Voltage 24VDC
Rated Amperage 60 Amps
Batteries 4 X 6 Volt 250-305-335AH @ 20 hr
rate
Scrub Brush Motors 2 X .75 hp (0.56 kW)
Vacuum Motor .75 hp (0.56 Kw)
Propelling Motor .3 hp (0.22 Kw)
Mass (GVW) 915 lbs. (415 kg) with 335 AH
Weight empty without batteries 346 lbs. (157 kg)
Solution Control Gravity feed, fully variable with
automatic shut-off in neutral
Solution tank capacity 23 gal. (87 l)
Recovery tank capacity 25 gal. (95 l)
Scrub brush diameter for 26 in. (66 cm) scrub head 13 in (33.0 cm)
Scrub brush diameter for 32 in. (81 cm) scrub head 16 in (41 cm)
Scrub brush pressure Actuated 0 lbs to 150 lbs (0 kg to 68
kg)
Scrub brush speed 200 rpm
Tires 2 x 10 in (25.4 cm) non-marking
foam-filled
Casters 2 X 4 in (10.2 cm) polyurethane solid
non-marking
Foundation Pressure (at recommended tire psi) 21 lbs./in 2 (140 kPa)
Maximum Speed 3.2 Miles/hour (5.2 km/hour)
Coverage with 26 in. (66 cm) scrub head 31,680 ft 2 /hour at 3.0 mph with
2 in. overlap*
Coverage with 32 in. (81 cm) scrub head 36,250 ft 2 /hour at 3.0 mph with
2 in. overlap*
Frame Construction Steel plate with epoxy powdercoat
finish.
Brakes (optional) Tire lock parking brake.
Minimum aisle u-turn width with 26 in. (66 cm) scrub head 64 in. (163 cm)
Minimum aisle u-turn width with 32 in. (81 cm) scrub head 69 in. (175 cm)
Maximum rated climb and descent angle with empty tanks and
without optional parking brake 2%
Maximum rated climb and descent angle with full tanks and
without optional parking brake 2%
* Cleaning rate results will vary depending on floor type, building structure, etc.
