MAINTENANCE

CUTTER 24V 86039080 04/17/07

4-2



1. Batteries
2. Squeegee
3. Aqua Mizer
4. Scrub Brushes
5. Float Shut-Off
6. Solution Strainer
7. Brush Motor
8. Traction Motor
9. Circuit Breakers
10. Brush Shroud & Brush Skirts

11. Vacuum Motor

12. Actuator Scrub Brush

9

8

7

6

5

3

4

2

1

11

10

12
