Page 11
COMPONENTS
CUTTER 24V 86039080 04/17/07
3-4
1. Control
Panel
2. Front Cover
3. Recovery Tank
4. Recovery Tank Drain Hose
5. Scrub Head Shrouds
6. Solution Tank
7. Solution Tank Cover
8. Solution Tank Drain Hose
9. Solution Strainer
10. Squeegee
11. Aqua-Mizer
12. Top Cover
13. Vacuum Motor
14. Recovery Tank Dome
15. Accessory Pump Port (Optional)
12
7
2
5
6
3
1
15
13
4
10
8
11
9
14
