Î Take out the brush.
Î Pull the water distribution bar out of
the brush tunnel (Fig. 5, see inside
front cover).
Î Clean the irrigation channel and the
opening in the water distribution bar
under running water.
Î Remove the solution tank from the
appliance.
Î Swivel support bow downward and
remove the recovery tank.
Î Pull the suction tube connection out
toward the rear of the appliance and
swivel out both ends of the suction
tube (Fig. 6, see inside front cover).
The suction tube is separated and
both ends are accessible for clean-
ing.
Î Pull the squeegee off toward the bot-
tom, the suction channel in the
cleaning head is accessible for
cleaning (Fig. 7, see inside front cov-
er).
Î Flush the suction hose and the suc-
tion channel with water or pull or
push the obstruction out with a blunt
object.
– Only use accessories and spare
parts which have been approved by
the manufacturer. The exclusive use
of original accessories and original
spare parts ensures that the appli-
ance can be operated safely and
troublefree.
– At the end of the operating instruc-
tions you will find a selected list of
spare parts that are often required.
Clean water distributor
Clean suction tube
Technical specifications
Power
Nominal voltage V/Hz 120 /
1~60
Average power con-
sumption W 600
Vacuuming
Cleaning power, air
quantity gpm
(l/s) 380
(24)
Cleaning power, neg-
ative pressure psi
(kPa) 2.0
(14)
Cleaning brush
Working width in
(mm) 12
(300)
Brush diameter in
(mm) 2.4
(60)
Brush speed 1/min 1550
Dimensions and
weights
Theoretical surface
cleaning performance ft²/h
(m²/
h) 2152
(200)
Fresh/dirty water res-
ervoir volume gal (l) 1 (4)
Length in
(mm) 15.4
(390)
Width in
(mm) 13.2
(335)
Height in
(mm) 46.5
(1180)
Weight (without tank
contents) lb
(kg) 24.3
(11)
Noise emission
Sound pressure level
(EN 60704-1) dB(A
) 71
Machine vibrations
Vibration total value
(ISO 5349) m/s² 0,5
Spare parts
