3/8" x 3 3/4" Bolt (90)
3/8" x 2 3/4" Carriage Bolt (83)
3/8" x 4" Bolt (66)
5
#8 x 3/4" Tek Screw (62)
#
3/8" x 1 1/2" Button Head Bolt (71)
3/8" x 1" Button Head Bolt (87)
3/8" x 2 3/4" Button Head Bolt (64)
3/8" x 3" Button Head Bolt (70) 3/8" x 2 1/4" Button Head Bolt (63)
3/8" x 2" Carriage Bolt (61)
3/8" x 5 1/2" Carriage Bolt (73)
3
3/8" x 4 1/2" Button Head Bolt (40)
5
5/16" x 4.69" All-thread Bolt (47)
3/8" x 4 1/4" Bolt (81)
5/16" x 4" Bolt (60)
1/4" x 1 3/4" Bolt (58)
1/4" x 3/4" Bolt (82)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST on the reverse side of this page. Find the quantity of
each part on the PART LIST.
Note: Some small parts may have been pre-attached. If a part is not in the
parts bag, check to see if it has been pre-attached. If a part is missing, call toll-free 1-877-992-5999.
