5
M6 Washer (32)
M10 Nylon
Locknut (42)
M
1
0
x
1
6
5
m
m
B
o
lt
(5
0
)
M8 x 70mm Bolt (46)
M10 Washer (55)
M8 Nylon
Locknut (36)
M10 x 90mm Carriage Bolt (43)
M10 x 90mm Bolt (45)
M10 x 85mm Bolt (44)
M6 x 80mm Screw (48)
M6 x 40mm Screw (51)
M10 x 77mm Bolt Set (47)
M4 x 19mm
Screw (54)
M8 Washer (49)
M6 x 20mm
Screw (53)
M5 x 19mm
Screw (52)
PART IDENTIFICATION CHART
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual.
Note: Some small parts may
have been preattached. If a part is not in the parts bag, check to see if it has been preattached. If a part
is missing, call 1-877-992-5999.
