Wolf W302210I User Manual
Page 7
7
Dimensions in parentheses are in
millimeters unless otherwise specified.
I N S TA L L AT I O N
I N S T R U C T I O N S
I N S TA L L AT I O N
S P E C I F I C A T I O N S
The following chart provides dimensions
specific to each wall hood model. These
dimensions are critical for proper installation.
Also refer to the illustration below.
Low-Profile Wall Hoods
Model
(A)
(B)
(C)
(D)
W302210I
30" (762)
7
1
/
2
" (191)
15" (381)
4
11
/
16
" (119)
W362210I
36" (914)
7
1
/
2
" (191)
18" (457)
4
11
/
16
" (119)
W362210
36" (914)
7
1
/
2
" (191)
18" (457)
4
11
/
16
" (119)
W422210
42" (1067)
7
1
/
2
" (191)
21" (533)
4
11
/
16
" (119)
W482210
48" (1219)
7
1
/
2
" (191)
24" (610)
4
11
/
16
" (119)
24" (610) Deep Wall Hoods
Model
(A)
(B)
(C)
(D)
W302418
30" (762)
9
1
/
2
" (241)
15" (381)
5
13
/
16
" (148)
W362418
36" (914)
9
1
/
2
" (241)
18" (457)
5
13
/
16
" (148)
W422418
42" (1067)
9
1
/
2
" (241)
21" (533)
5
13
/
16
" (148)
W482418
48" (1219)
9
1
/
2
" (241)
24" (610)
5
13
/
16
" (148)
W542418
54" (1372)
9
1
/
2
" (241)
27" (686)
5
13
/
16
" (148)
W602418
60" (1524)
9
1
/
2
" (241)
30" (762)
5
13
/
16
" (148)
W662418
66" (1676)
9
1
/
2
" (241)
33" (838)
5
13
/
16
" (148)
27" (686) Deep Wall Hoods
Model
(A)
(B)
(C)
(D)
W302718
30" (762)
9
1
/
2
" (241)
15" (381)
5
13
/
16
" (148)
W362718
36" (914)
9
1
/
2
" (241)
18" (457)
5
13
/
16
" (148)
W422718
42" (1067)
9
1
/
2
" (241)
21" (533)
5
13
/
16
" (148)
W482718
48" (1219)
9
1
/
2
" (241)
24" (610)
5
13
/
16
" (148)
W542718
54" (1372)
9
1
/
2
" (241)
27" (686)
5
13
/
16
" (148)
W602718
60" (1524)
9
1
/
2
" (241)
30" (762)
5
13
/
16
" (148)
W662718
66" (1676)
9
1
/
2
" (241)
33" (838)
5
13
/
16
" (148)
Letters correspond to those in the illustration.
C
TO CENTER
OF TRANSITION
D
A
WIDTH
OF HOOD
TO CENTER
OF TRANSITION
B
HEIGHT OF
TRANSITION
