W O L F
P R O WA L L V E N T I L AT I O N
H O O D S
30"
TO
36"
(762–914)
TO COUNTERTOP
30"
TO
36"
(762–914)
TO COUNTERTOP
10"
(254)
18"
(457)
HEIGHT
OF HOOD
22"
(559)
24"
(610)
DEPTH OF HOOD
WIDTH OF HOOD
NOTE: Low-profile and 24" (610) deep wall hoods have a vertical or horizontal discharge; discharge direction varies with blower model.
E
6"
(152)
5"
(127)
LOCATION OF ELECTRICAL
30"
TO
36"
(762–914)
TO COUNTERTOP
30"
TO
36"
(762–914)
TO COUNTERTOP
18"
(457)
HEIGHT
OF HOOD
27"
(686)
DEPTH OF HOOD
WIDTH OF HOOD
E
6"
(152)
5"
(127)
LOCATION OF ELECTRICAL
NOTE: 27" (686) deep wall hoods are vertical discharge only.
I N S TA L L AT I O N
S P E C I F I C A T I O N S
Low-Profile and
24" (610) Deep
Wall Hoods
27" (686) Deep
Wall Hoods
