TECHNICAL SPECIFICATIONS
SCEX364 86037160 03/12/07 3-1
ITEM DIMENSION/CAPACITY
Nominal power
1440 Watts
Rated Voltage 24VDC
Rated Amperage 60 Amps
Batteries 4 X 6 Volt 250-305-335AH @ 20
hr rate
Scrub Brush Motors .33 hp (0.25 Kw)
Vacuum Motor .75 hp (0.56 Kw)
Propelling Motor .3 hp (0.22 Kw)
Mass (GVW) 956 pounds (433 kg)
Weight empty without batteries 395 pounds (179 kg)
Solution Control Gravity feed, fully variable with
automatic shut-off in neutral
Solution tank capacity 23 gal. (87 l)
Recovery tank capacity 25 gal. (95 l)
Scrub brush diameter for 36 in. (90 cm) scrub head 12 in (30.0 cm)
Scrub brush pressure Actuated 0 lbs to 150 lbs (0 kg to
68 kg)
Scrub brush speed 165 rpm
Tires 2 x 10 in (25.4 cm) non-marking
foam-filled
Casters 2 X 4 in (10.2 cm) polyurethane
solid non-marking
Foundation Pressure (at recommended tire psi) 48 psi
Maximum Speed 3.2 Miles/hour (5.2 km/hour)
Coverage with 36 in. (90 cm) scrub head 277 sq. ft/min
Frame Construction Steel plate with epoxy
powdercoat finish.
Brakes Tire lock parking brake.
Minimum aisle u-turn width with 36 in. (90 cm) scrub head 73” (185 cm)
Maximum rated climb and descent angle with empty tanks 2%
Maximum rated climb and descent angle with full tanks
2%
* Cleaning rate results will vary depending on floor type, building structure, etc.
