MAINTENANCE
SCEX364 86037160 03/12/07
4-2
1. Batteries
2. Rear Squeegee
3. Scrub Brushes
4. Float Shut-Off
5. Solution Strainer
6. Brush Motor
7. Traction Motor
8. Circuit Breakers
9. Scrubhead Fixed and Swinging
10. Vacuum Motor
11. Actuator Scrub Deck Up-Down
12. Actuator Scrub Deck In-Out
13. Side Squeegee
5
7
2
8
4
1
11
12
9
3
10
13
6
