Components – Windsor Saber Cutter SCEX364 User Manual
Page 11
COMPONENTS
SCEX364 86037160 03/12/07
3-4
1. Control
Panel
2. Front Cover
3. Recovery Tank
4. Recovery Tank Drain Hose
5. Scrub Head Fixed
6. Solution Tank
7. Solution Tank Cover
8. Solution Tank Drain Hose
9. Solution Strainer
10. Rear Squeegee
11. Top Cover
12. Vacuum Motor
13. Recovery Tank Dome
14. Scrub Head Swinging
15. Side Squeegee
16. Park Brake
4
9
10
8
16
1
13 3
11
12
6
15
14
5
2
7
