Page 21
Dual Outlet Duct
Attic Mounted System
STANDARD DUCTED INSTALLATION
Heat Exhaust
Cold Air Supply-Cellar
Condenser Intake
Return Air-Cellar Side
It is recommended to use our Insulation Box and Condensate Pan for this application. See page 34 for more
information or visit www.whisperkool.com
Condenser Exhaust
Insulation Box
Cold Air
Return Air
Condenser
Intake
Fresh Air
Intake
