OPERATION CONTROLS
1
2
3
4
5
6
7
8
9
10
11
12
Brush Switch. Turns brush
Vacuum Switch. Turns vacuum
motor
Main Handle.
Brush Motor Circuit Breaker.
Protects brush motor from overheating.
Vacuum Motor Circuit Breaker.
Protects vacuum motor from overheating.
Solution Lever. Controls the amount of
solution flow to the floor.
Squeegee Lift Lever. Raises and
lowers squeegee.
Scrub Deck Lift Lever. Raises and lowers
scrub deck.
Recovery Tank Drain Hose.
Solution Tank Drain Hose.
Squeegee Release Latch. Releases
the rear squeegee blade for adjustment
or replacement.
Battery Compartment Door Latch. Opens
back
13 Vacuum Hose.
of machine for access to batteries.
11
6
TOP \
\
2
1
BA
13
'
6
98447 7/1/97
