TECHNICAL SPECIFICATIONS
SCX364 86037150 1/17/07 3-1
ITEM DIMENSION/CAPACITY
Nominal power 1440 Watts
Rated Voltage 24VDC
Rated Amperage 60 Amps
Batteries
4 X 6 Volt 250-305-335AH @ 20 hr
rate
Scrub Brush Motors .33 hp (0.25 Kw)
Vacuum Motor .75 hp (0.56 Kw)
Propelling Motor .3 hp (0.22 Kw)
Mass (GVW) 956 pounds (433 kg)
Weight empty without batteries 395 pounds (179 kg)
Solution Control
Gravity feed, fully variable with
automatic shut-off in neutral
Solution tank capacity 23 gal. (87 l)
Recovery tank capacity 25 gal. (95 l)
Scrub brush diameter for 36 in. (90 cm) scrub head 12 in (30.0 cm)
Scrub brush pressure
Actuated 0 lbs to 150 lbs (0 kg to 68
kg)
Scrub brush speed 165 rpm
Tires
2 x 10 in (25.4 cm) non-marking
foam-filled
Casters
2 X 4 in (10.2 cm) polyurethane solid
non-marking
Foundation Pressure (at recommended tire psi) 48 psi
Maximum Speed 3.2 Miles/hour (5.2 km/hour)
Coverage with 36 in. (90 cm) scrub head 277 sq. ft/min
Frame Construction
Steel plate with epoxy powdercoat
finish.
Brakes (optional) Tire lock parking brake.
Minimum aisle u-turn width with 36 in. (90 cm) scrub head 73” (185 cm)
Maximum rated climb and descent angle with empty tanks and
without optional parking brake
2%
Maximum rated climb and descent angle with full tanks and
without optional parking brake
2%
* Cleaning rate results will vary depending on floor type, building structure, etc.
