CONTROLS
SCX364 86037150 1/17/07
3-6
1. Key Switch
2. Emergency Shut Off Switch (Optional)
3. Speed Control Knob
4. Propel Control Lever
5. Reverse Button
6. Brush Switch
7. Actuator Switch Deck Up-Down
8. Solution Control Knob
9. Vacuum Switch 10. Squeegee Lift Lever
11. Squeegee Pitch Adjustment Knob
12. Squeegee Deflection Adjustment Knobs
13. Battery Charge Level Indicator
14. Parking Brake (Optional)
15. Hour Meter
16. Brush Pressure Indicator
17. Actuator Switch Deck In
-Out
1. KEY SWITCH
Controls the power for machine functions.
To turn machine on, rotate key clockwise.
To turn machine off, rotate key
counterclockwise.
FOR SAFETY: Always remove the key when
machine is unattended or during service to
prevent unauthorized movement.
2. EMERGENCY SHUT-OFF SWITCH
(OPTIONAL)
Shuts off machine.
To shut off machine, push the switch.
To restart machine, rotate the switch clockwise.
3. SPEED CONTROL KNOB
Controls the speed of the machine.
To increase speed, rotate knob clockwise.
To decrease speed, rotate knob
counterclockwise.
4. PROPEL CONTROL LEVERS
Controls the machine direction, and scrub
brushes and solution flow.
To propel machine forward, squeeze either
propel lever.
The scrub brushes will not rotate and the
solution will not flow to scrub deck with the
propel levers in neutral.
5. REVERSE BUTTON
Controls the reverse function.
To propel machine backward, push the reverse
button then squeeze either propel lever.
To stop machine, release both propel levers
then release the reverse button.
6. BRUSH SWITCH
Controls the scrub brush motors.
To turn scrub brushes on, press the bottom of
the switch. The brushes will not rotate with the
propel control levers in neutral.
To turn scrub brushes off, press the top of the
switch.
