MAINTENANCE

SCX364 86037150 1/17/07

4-2
































1.

Batteries

2.

Rear Squeegee

3.

Scrub Brushes

4.

Float Shut-Off

5.

Solution Strainer

6.

Brush Motor

5

7

2

8

4

1

11

12

9

3

10

13

6

7.

Traction Motor

8.

Circuit Breakers

9.

Scrubhead Fixed and Swinging

10.

Vacuum Motor

11.

Actuator Scrub Deck Up-Down

12.

Actuator Scrub Deck In-Out

13.

Side Squeegee
