Weil-McLain SERIES 7 PFG - Manual (Page 16)

16
PFG S
erieS
7 G
aS
-
Fired
W
ater
B
oiler
– U
niverSal
C
ontrol
S
yStemS
Part Number 550-110-643/0605
Section E: Parts
**Not for use on Canadian PFG-8 boilers.
Only dampers listed above are approved for use on and PFG Series 6 & 7 boilers.
Any other damper installed can cause severe personal injury or death.
Part Description Vendor Part Number W-M
Part No.
Damper Assembly
PFG-5)
8" (PFG-6)
9" (PFG 7-8)
Effikal RVGP-KS-7BKF
Johnson Q35GH-2 consisting of M35BC actuator and Y15 vent
pipe
Effikal RVGP-KS-8BFK
Johnson Q35GK-2 consisting of M35BC actuator and Y15 vent
pipe
Effikal RVGP-KS-9BF**
Johnson Q35GM-2 consisting of M35BC actuator and Y15 vent
pipe**
381-800-477
381-800-478
381-800-445
Damper Actuator Effikal RVGP (Effikal Only)
Johnson M35BE-1C (Johnson Only) 510-512-337
510-312-255
Damper Harness Weil-McLain 591-391-795
UCS Ignition Control Honeywell S8620C1003
United Technologies 1003-511 511-330-097
Pilot Burner Assembly Johnson Controls Q90GE-1 consisting of J981LYW pilot and
Y75AA-3 flame sensor 511-330-218
Boiler Wiring Harness, PFG-5
Boiler Wiring Harness, PFG 6-8
Weil-McLain
Weil-McLain
591-391-878
591-391-880
Gas Valve 3/4" X 3/4"
PFG 5
Gas Valve 3/4" X 1"
PFG 6-7
Gas Valve 1" X 1"
PFG-8
Honeywell VR8304P4348
White-Rodgers 36C74-474
Robertshaw 7000 DERHC-S7C
Robertshaw 7000 DERHC-S7C
511-044-382
511-044-286
511-044-287
