Windsor 10080480 - Manual (Page 9)

OPERATIONS
86302100 CLIPPER DUO 10/02/07 3-1
TECHNICAL SPECIFICATIONS
ITEM DIMENSION/CAPACITY
Construction Steel chassis with rotationally molded polyethylene tanks
Vacuum Motor Three stage, bypass, 1.5 hp (1,119 watts), 100 cfm
(2.8m³/min), 120” (3050 mm) waterlift
Solution Pump 100 psi (7 bar) – Restorative
50 psi (3.5 bar) - Interim
Brush Motor 1/2 hp (604 watts) AC with circuit breaker protection
Brushes 2 x 16” (406 mm), ABS core, Perform Alert™ bristle spiral
pattern
Cleaning Path 16” (40.6 cm)
Cleaning Rate Interim – 10,560 ft²/hr (981 m²/hr)
Restorative – 3,520 ft²/hr (327 m²/hr)
Flow Rate Interim - 0.09 gpm ( 0.37 lpm)
Restorative – 1.0 gpm (37.8 lpm)
Solution Spray Interim – One quick-disconnect jet
Restorative - One quick-disconnect jet
Solution Tanks 10 gallons ( 37.8 l)
Recovery Tank 10 gallons (37.8 l)
Vacuum Shoe 18” (458 mm) wide, cast aluminum
Wheels 10” (254 mm) non-marking rubber
Power Cable 50’ (15 m) detachable
Weight 166 lbs (75.3 kg) with cord
