Page 17
17
9
Part List:
Snow
Thrower
For parts and/or
accessories
please call
1-800-949-4483
www.whiteoutdoor.com
Model S235
REF
NO.
PART NUMBER
DESCRIPTION
Qty.
1
684-04127
Chute Assembly
1
2
710-04071
Carriage Bolt 5/16-18 x 1.0”
1
3
710-0451
Carriage Bolt 5/16-18 x 0.750”
1
4
712-04063
Flange Lock Nut, 5/16-18
7
5
720-04072
Star Knob, 5/16-18
2
6
731-04388A
Chute Handle
1
7
731-04426A
Upper Chute
1
8
736-0119
Lock Washer, 5/16
1
9
710-04532
Carriage Screw, 5/16-18 x 2.0 Gr. 5
2
10
732-04111
Chute Adjustment Spring
1
11
725-0157
Cable Tie
1
12
710-0805
Screw, 5/16-18 x 1.50
4
13
747-04159
Bail, Gull Wing
1
14
749-04106
Upper Handle, Gull Wing
1
15
684-04161
Shroud Assembly
1
16
710-04187
Screw, 1/4-15 x .50
3
17
710-1003
Self-tapping Screw, #10-16 x .625”
3
18
710-1882
Hex Flange Screw 5/16-18 x 1.50 Gr. 5
4
19
712-0252
Hex Nut 5/8-32 x .12 Special
1
20
725-2018
Key Switch-Electric Start
1
21
736-0225
Lock Washer Internal .625 x 1.058
1
22
736-0400
Flat Washer .194” x .62” x .063
5
23
750-0589
Spcr., .325 ID x .625 OD x .88 Lg.
4
24
736-0362
Flat Washer .330 x 1.25 x .06
2
25
710-0134
Screw, 1/4-20 x .62
8
26
710-3008
Truss Machine Screw, 5/16-18 x .75
1
27
712-04064
Hex Flange Lock Nut, 1/4-20
9
28
731-1033
Shave Plate,19.88
1
29
736-0176
Flat Washer .265 x .938 x .120
3
30
746-04237
Control Cable
1
31
749-04114
Lower Handle
1
32
725-0201
Ignition Key
2
33
731-1133C
Spark Plug Cover
1
34
731-04127
Lower Chute 5” Dia
1
35
731-04353
Ring-Lower Chute
1
36
731-04886
Chute, Adapter 5” Dia
1
