Page 15
15
9
Part List:
Snow
Thrower
NOTE: For a proper working machine,
use Factory Approved Parts. V-belts are
designed to engage and disengage safely.
A substitute (non OEM) V-belt can be
dangerous by not disengaging completely.
NOTE: Snow thrower features/components vary by model. NOT all parts listed above and pictured on the previous
page are standard equipment.
† If Equipped
†† Pulley Hole 1/4”
* Pulley Hole 3/8”
For parts and/or
accessories
please call
1-800-949-4483
www.whiteoutdoor.com
Model S235
REF
NO.
PART No.
DESCRIPTION
Qty.
1
629-0236†
Extension Cord
1
2
710-0627
Hex Screw, 5/16-24 x .75
1
3
710-1003†
Screw, #10-16 x .625
2
4
7510009630 Recoil Handle
1
5
712-04063
Hex Flange Lock Nut, 5/16-18
2
6
722-3022
Foam Tape .625 X.25
2
7
726-0154
Push Mount Cable Tie
1
8
726-0205
Clamp, Hose
2
9
750-0716A
Spcr., .630 x .880 x .747
1
10
736-0242
Bell Washer, .340 x .872 x .060
1
11
747-04150
Gas Tank Support Wire
1
12
7511825510 Choke Lever Knob
1
13
751-0535
Hose, Fuel Line
18
14
751-10023
Tank, Fuel
1
15
751-10278
Cap, Fuel
1
16
754-0367
V-Belt, 3/8 x 34.4 Lg.
1
17
756-0416B
Pulley Half, .625 ID x 2.25 OD
2
18
756-04243
Pulley, V Type, 3/8 x 6.0 OD
1
19
790-00225
2-Cycle Mounting Bracket
1
20
734-04204
Wheel, 7 x 1.5 Dia. Tread
2
21
684-04228
Auger Assembly Complete
1
22
710-0106†† Hex Screw, 1/4-20 x 1.00 Gr. 5
1
710-0191*
Hex Screw 3/8-24 x 1.25
1
23
710-0642
Hex Screw 1/4-20 x .75 Gr. 5
1
24
710-0653
Self-tapping Screw 1/4-20 x .375
1
25
710-0896
Hex Screw, 1/4-14 x 0.625”
24
REF
NO.
PART No.
DESCRIPTION
Qty.
26
710-0352
Screw, 1/4-14 x .375
6
27
684-04227
Auger Assembly Housing 21”
1
28
712-04064††
Hex Flange Lock Nut, 1/4-20
1
712-0116*
Jam Lock Nut 3/8--24
1
29
726-0299
Push Cap, 1/2”
2
30
732-0357A
Extension Spring
1
31
736-0176
Flat Washer .265 x .938 x .120
1
32
721-04006
Fuel Tank Gasket
2
33
736-0329
Lock Washer, 1/4
1
34
741-04188
Ball Bearing
2
35
684-04168††
Idler Pulley
1
756-0313*
Idler Pulley
1
36
748-0234
Shoulder Spacer .25
1
37
712-0896
Hex Lock Nut 1/4-28
1
38
790-00249
Bearing Cup
2
39
790-00283††
Idler Brkt. w/Brake
1
790-00238*
Idler Brkt. w/ Brake
1
40
790-00045A
Belt Cover
1
41
756-0625
Cable Roller
1
42
735-04033
Rubber Paddle
2
43
735-04032
Crescent Spiral
4
44
750-04571
Shldr., Spcr., .260 x .785 x .538
1
45
7510009636†
Recoil Handle, Mitten
1
46
7512B1476
Primer
1
47
738-0924A
Carriage Screw 1/4-28
1
