33
Update
• Fixed Code Length Qualification
Select Fixed Length Qualification
Fixed Length 1 *
Fixed Length 2 *
Programming Instructions: (1) Read the label. (2) Program the desired length
by reading Decimal Digits on page 53. (3) Read the “Validate” label (also on
page 53) to complete this setting.
EAN128 Parameters EAN128 Parameters EAN128 Parameters EAN128 Parameters
• Code ID Transmission
Enable
• Field Separator
*
Programming Instructions: (1) Read the label. (2) Program the desired
character string by reading Hexadecimal Digits on page 54. One character
consists of 2 hexadecimal digits. (3) Read the “Validate” label (also on page
54) to complete this setting.
34
Enter Setup
EAN8 Parameters EAN8 Parameters EAN8 Parameters EAN8 Parameters
• Convert to EAN13
Enable
< Disable >
• Checksum Transmission
< Enable >
Disable
UPCA P UPCA P UPCA P UPCA Parameters arameters arameters arameters
• Convert to EAN13
< Enable >
Disable
• System Number Transmission
< Enable >
Disable
• Checksum Transmission
< Enable >
Disable
