P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 1 / 1 5 / 0 9
© 2 0 0 9 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In Classic Chimney Glass Wall Hood
Recirculating Hood Conversion Kits
• For DGWH only
• Eliminates ducting
• Kit includes
o Charcoal filter
o Installation hardware
o Top vent/grille
• Air diverter
• Reducing collar
Duct Cover Extensions
• For DGWH only
• 11-1/2”W. x 12”D. x 36”-56”H.
• Extends height of hood by up to 12” (for 10’ ceilings)
• Replaces adjustable duct cover supplied with hood
• Specify finish code following accessory model number (for example, DGCE1210-SS)
• Available in Stainless Steel (SS)
Compliance Information
WARRANTY SUMMARY*
• One-year full warranty—complete product
• Five-year limited warranty—all ventilator motors
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items
*Must use Viking ventilator kits with Viking hoods; use of non-Viking kits voids product warranty. For complete warranty see Use & Care Guide.
Warranty valid on Viking products shipped within the United States and Canada.
✪ Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
DGRK36 36”W. glass hood 3 (1.1)
Model Description Approx. ship wt. lbs. (kg)
DGCE1210 Designer glass duct cover extension 12 (5.4)
