98 - User's Manual
axisz 4096 ~ 8859 1/7 Axis Z coordinate, used internally
defaulthome 0,1 1/4 0: user define home
1: default home
returnhome 0,1 1/4 Enable return home position while idle.
returnhomeinterval 0 ~ 9999 1/4 Time span for idle duration
osdzoom 0,1 1/4 Enable zoom times display
preset_i<0~19>_name string[40] 1/4 The name of preset location
preset_i<0~19>_pan -6790 ~ 6790 1/4 The axis x coordinate of each preset location
preset_i<0~19>_tilt -786 ~ 1572 1/4 The axis y coordinate of each preset location
preset_i<0~19>_zoom 4096 ~ 8859 1/4 The axis z coordinate of each preset location
patrol_i<0~39>_name string[40] 1/4 The name of patrol location
Group: privacymask_c<0~(n-1)> for n channel product
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable 4/4 Enable the privacy mask
win_i<0~4>_enable 4/4 Enable the privacy mask window
win_i<0~4>_name string[14] 4/4 The name of privacy mask window
win_i<0~4>_left 0 ~ 320/352 4/4 Left coordinate of window position.
win_i<0~4>_top 0 ~ 240/288 4/4 Top coordinate of window position.
win_i<0~4>_width 0 ~ 320/352 4/4 Width of privacy mask window
win_i<0~4>_height 0 ~ 240/288 4/4 Height of privacy mask window
Group: capability
NAME VALUE SECURITY
(get/set)
DESCRIPTION
api_httpversion 0200a 0/7 The HTTP API version.
bootuptime
integer>
0/7 The server bootup time
nir 0,
integer>
0/7 number of IR interface
ndi 0,
integer>
0/7 number of digital input
ndo 0,
integer>
0/7 number of digital output
naudioin 0, 0/7 number of audio input
