INSTALLATION DIRECTIVE
MAY 2006
8
V08 EnT M75 - M11 - M12
Connectors
J1
on the relay box panel for external diagnostic
tool
J1
70-pole EDC - boat components connections
J2
70-pole EDC - engine components connections
J3
lubrication oil transfer electrical pump
J4
pre-lubrication electrical pump
JA
connection between engine wiring and interface
wire harness
JB
On EnGInE WIRE HARnESS
ready for connection to the main analog
instrument panel
JC
On MAIn AnALOG InSTRUMEnT PAnEL
ready for connection to the engine wire harness
JD
IVECO MOTORS indications and alarms module
JE
On MAIn AnALOG InSTRUMEnT PAnEL
ready for connection to the secondar y
analog instr ument panel
JF1,JF2
relay box
JH
On SECOnDARY AnALOG InSTRUMEnT PAnEL
ready for connection to the main analog
instrument panel
Indicator lights
EDC
EDC malfunction
SAC
presence of water in fuel prefilter
SATA
coolant high temperature
SBLA
low coolant level
SBPO
low oil pressure
SCP
pre-post heating
SIFA
clogged air filter
SIFB
clogged oil vapour filter
SIFC
clogged fuel filter
SIFO
clogged oil filter
SIM
expired programmed maintenance interval
SP
pre-lubrication
SS
alternator fault
SSV
engine overspeed
Gauges
CG
revolution-counter
MI
gear box oil pressure
MO
engine oil pressure
TA
engine temperature
TI
gear box oil temperature
TS
exhaust gas temperature
V
voltmeter
Relays contained in the relay box
K1
key switch electric discharge
K2
IGnITIOn switch electric discharge
K3
power supply to terminal 50 of the electric
starter motor
K4
start request signal, from key switch to EDC
electronic unit
K5
TGC control ready
KR
EDC blink code emission LED control
Fuses contained in the relay box
F1- F2
self restoring (not replaceable)
