INSTALLATION DIRECTIVE V08 EnT M75 - M11 - M12 MAY 2006
Page
CONTENTS
Indications for consultation
The different versions of the motors are generally shown
using the same pictures and descriptions, however important
differences are shown separately.
1. WARnInGS AnD CAUTIOnS 4
2. EnGInE PARTS AnD COMPOnEnTS 6
3. InSTALLATIOn OVERVIEW 10
4. GEnERAL InSTALLATIOn CRITERIA 11
5. TECHnICAL DATA FOR InSTALLATIOn 12
6. IDEnTIFICATIOn DATA 14
7. FUEL LInE 15
8. ELECTRICAL EQUIPMEnT 17
9. MAIn AnALOG InSTRUMEnT PAnEL 26
10. SECOnDARY AnALOG InSTRUMEnT PAnEL 30
11. DRILLInG PLAnS FOR AnALOG PAnELS 31
12. CUSTOMIZED InSTRUMEnT PAnEL 32
13. SEnSORS FOR DETECTIOn
AnD InSTRUMEnT PAnEL SIGnALLInG 34
14. PREPARInG THE EnGInE FOR FIRST START-UP 37
15. TESTS BEFORE THE FIRST START-UP 37
16. FIRST EnGInE START 38
17. EDC ECU InDICATIOn LIGHTS 40
18. UnDERWAY CHECKS 43
19. PREPARInG THE EnGInE
FOR LOnG IDLE PERIODS 44
20. ELECTRIC DIAGRAMS 46
21. APPEnDIX 53
