P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E L E A S E D 1 2 / 1 / 0 7
© 2 0 0 7 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In VersaVent™ Rear Downdraft
Interior-Power Blower Kit
• Stainless Steel (SS)
• Mounts on any size plenum
• 3-1/4” x 10” duct takeoff
• Can transition to 6” round
• Can run duct to left, right, or down
• Max. duct run—40’ (12.2 m)
• Kit includes motor, downdraft plug, and 3-1/4” x 10” collar (for installers who prefer to rivet the ductwork to the
unit.)
Note: Exhaust capacity based on tests with 0.1 static pressure. Without applying static pressure (some brands do not),
CFM could be greatly overstated
Exterior-Power Blower Kit
• Stainless Steel (SS)
• Mounts on wall or roof (no roof cap required)
• Comes with 10” round duct takeoff plate, which mounts on any size plenum
• Max. duct run—50’ (15.2 m)
• Kit includes motor, downdraft plug, and 3-1/4” x 10” collar (for installers who prefer to rivet the ductwork to the
unit.)
• VEDV1200 must be used with VIPR181/181R
Note: Exhaust capacity based on tests with 0.1 static pressure. Without applying static pressure (some brands do not),
CFM could be greatly overstated
Remote Mounted Control
• Replaces standard Designer control
• Gray control panel and membrane with stainless steel trim—coordinates with white Designer cooktops
• Easy to install
• Must be mounted into the countertop, 4” min. from burners
• 4”W. x 2-1/2”D.
Compliance Information
WARRANTY SUMMARY*
• One-year full warranty—complete product
• Five-year limited warranty—all ventilator motors
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items
*Must use Viking ventilator kits with Viking downdrafts; use of non-Viking kits voids product warranty. For complete warranty see Use & Care Guide.
Warranty valid on Viking products shipped within the United States and Canada.
✪ Installation Notes & Accessories
Model Description Max. amp usage Approx. ship wt. lbs. (kg)
VIDV500 500* CFM downdraft blower 4.0 32 (14.4)
Model Description Max. amp usage Approx. ship wt. lbs. (kg)
VEDV900 900 CFM downdraft blower 5.7 42 (18.9)
VEDV1200 1200 CFM downdraft blower 3.0 44 (19.8)
Model Description Approx. ship wt. lbs. (kg)
DSRCGY Designer remote mounted control (SS/gray) 1.5 (0.7)
