PARTS LIST
FIREPLACE
VSGF28NTC
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 22 of this manual.
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 101357-01 Top Outer Casing 1
2 103207-01 Outer Casing 1
3 102758-02CK Right Front Side 1
4 102759-02CK Left Front Side 1
5 098304-01 Phillips Pan Head Screw, #10 17
6 101351-01CK Top Front 1
7 102455-02 Top Louver Assembly 2
8 101353-01CK Middle Front Rail 1
9 101712-02 Firebox Hood 1
10 101348-01 Firebox Support 2
11 099230-01 Shoulder Screw 4
12 101872-03 Firebox Top 1
13 101346-01CK Outer Base 1
14 101838-03CJ Firebox Wrapper 1
15 101614-02 Limit Switch (thermal disk) Assy. 1
16 M11084-26 Hex Screw, #10 57
17 098304-03 Phillips Pan Head Screw, #8 4
18 101727-03 Screen Assembly 1
19 101398-03 Wire Harness 1
20 103650-01 Control Knob 1
21 103581-02 Blower Assembly 1
22 099123-01 Wire Clip 4
23 105649-01 Blower Speed Control 1
24 M11084-38 Hex Screw, 8-18 x .38" 4
25 101629-01 Plastic Bushing 2
26 098544-01 Clamp 1
PARTS AVAILABLE — NOT SHOWN
099038-01 Strain Relief Bushing 1
100639-01 Caution Decal 1
103590-01 Decal Strip 1
104313-01 Hinge, Pin 1
104313-02 Hinge, Pin 1
M10908-2 Screw, Slotted Hex Head Tapping 4
