Page 27
27
107157
OWNER’S MANUAL
For more information, visit www.desatech.com
PARTS LIST
FIREPLACE
VSGF28NVA
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 22 of this manual.
KEY
NO.
PART NUMBER
DESCRIPTION
QTY.
1
101357-01
Top Outer Casing
1
2
103207-01
Outer Casing
1
3
102758-02CK
Right Front Side
1
4
102759-02CK
Left Front Side
1
5
098304-01
Phillips Pan Head Screw, #10
17
6
101351-01CK
Top Front
1
7
102455-02
Top Louver Assembly
2
8
101353-01CK
Middle Front Rail
1
9
101712-02
Firebox Hood
1
10
101348-01
Firebox Support
2
11
099230-01
Shoulder Screw
4
12
101872-03
Firebox Top
1
13
101346-01CK
Outer Base
1
14
101838-03CJ
Firebox Wrapper
1
15
101514-01CK
Cover
1
16
M11084-26
Hex Screw, #10
57
17
098304-03
Phillips Pan Head Screw, #8
4
18
101727-03
Screen Assembly
1
PARTS AVAILABLE — NOT SHOWN
100639-01
Caution Decal
1
103590-01
Decal Strip
1
104313-01
Hinge, Pin
1
104313-02
Hinge, Pin
1
M10908-2
Screw, Slotted Hex Head Tapping
4
