D E S I G N E R H O O D S *
V E N T I L A T O R K I T
(when used over ranges/rangetops with char-grill)
W A L L A N D I S L A N D H O O D S
All 18" high rangehood ventilator kits include rough-in kit, transition to round duct (7" round for VIV600 – all other 10" round), and damper (if applicable).
All ventilator kits use 120VAC/60Hz.
Proper installation is extremely important to ensure maximum performance from any ventilation product.
1. All CFMs stated based on tests with .1 static pressure; without applying static pressure (some brands consciously do not), CFM could be greatly overstated.
2. Duct run length is for general reference only; for longer duct runs, increase duct size and contact a qualified and trained installer.
• Straight runs and gradual turns are best; for example, each 90-degree elbow is equal to 5-10 feet (1.52-3.05 m) of straight run.
• Never use flexible duct; it creates back pressure/air turbulence and greatly reduces performance.
• Proper performance is dependent upon proper ducting; make sure that a qualified and trained installer is used.
• Check with a qualified and trained installer or local codes for makeup air requirements, if any.
D O W N D R A F T S
300 440 600 880 1,200 900 1,200 1,500 500 900 1,200
See Specifications 3 1/4"x10" 10" round
(can transition
to 6" round)*
50 ft. (15.2 m) 75 ft.(22.8 m) 40 ft.(12.1 m)
See Specifications 4.0 6.0
Model
Interior
Ventilators
Ventilator kits – Professional and Designer
Exterior
Ventilators
Exterior
Ventilators
Interior
Ventilators
DIV440 VIV600
DIV600 DIV880 VIV1200
DIV1200 VEV900
DEV900 VEV1200
DEV1200 VIDV500 VEDV900 VEDV1200
APPROXIMATE CFM 1
RECOMMENDED
DUCT SIZE
MAXIMUM DUCT RUN 2
MAXIMUM AMPS
30", 33", 36", 39", 42", and 45" wide hoods – Classic Chimney models and
Built-in Custom Ventilator Systems as noted below
36" and 42" wide hoods – Tall Traditional models as noted below
48" wide hoods – Tall Traditional models as noted below
48" and 51" wide hoods – Classic Chimney models and Built-in Custom
Ventilator Systems as noted below
1,200 CFM exterior ventilator kit (DEV1200)
1,200 CFM interior or exterior ventilator kit (VIV1200 or VEV1200)
1,200 CFM interior or exterior ventilator kit (VIV1200 or VEV1200)
or 1,500 CFM exterior ventilator kit (VEV1500)
1,200 CFM interior or exterior ventilator kit (DIV1200 or DEV1200)
or 1,500 CFM exterior ventilator kit (DEV1500)
* Includes the following wall hoods: Classic Chimney, Classic Chimney with Ledge, Classic Chimney Ledgeless, Built-in Custom Ventilation Systems (for wall hoods),
Tall Traditional with Ledge, and Tall Traditional Ledgeless. (Slim Traditional wall hoods, Box wall hoods, Classic Chimney island hoods, and Island Custom Ventilator Systems
should not be installed over Professional ranges and rangetops with the gas char-grill feature.)
Designer hoods can be installed over Professional cooking products. However, when choosing a Professional range or rangetop with the
gas char-grill feature, the following ventilator kits must be used to ensure proper performance:
VEV1500
DEV1500 VIV300
DIV300
Requirements for Designer hoods installed over Professional
cooking products with char-grill feature
36 37
R E A R D O W N D R A F T S
Model
Number
of Filters Interior Exterior
Recommended Ventilator Kits Recommended Duct Size
Interior Exterior
Maximum Amps
Interior Exterior
Rear downdrafts – Professional
30" W. VIPR101(R)SS 2 VIDV500 VEDV900/VEDV1200 10" 10" 4.0 6.0
36" W. VIPR161(R)SS 2 VIDV500 VEDV900/VEDV1200 10" 10" 4.0 6.0
48" W. VIPR181(R)SS 2 VIDV500 VEDV900/VEDV1200 10" 10" 4.0 6.0
(can transition
to 6" round)
(can transition
to 6" round)
(can transition
to 6" round)
R E A R D O W N D R A F T S
Model
Number
of Filters Interior Exterior
Recommended Ventilator Kits Recommended Duct Size
Interior Exterior
Maximum Amps
Interior Exterior
Rear downdrafts – Designer
30" W. DIPR100RSS 2 VIDV500 VEDV900/VEDV1200 10" 10" 4.0 6.0
36" W. DIPR160RSS 2 VIDV500 VEDV900/VEDV1200 10" 10" 4.0 6.0
45" W. DIPR150RSS 2 VIDV500 VEDV900/VEDV1200 10" 10" 4.0 6.0
(can transition
to 6" round)
(can transition
to 6" round)
(can transition
to 6" round)
