B U I L T - I N C U S T O M V E N T I L A T I O N S Y S T E M S
Model Number
of
Lights
Number
of
Filters
Heat
Lamps Interior Exterior
Recommended Ventilator Kits Recommended
Duct Size
Interior Exterior
Maximum
Amps
Interior Exterior
* A 1,200 CFM interior- or exterior-power ventilator should be used when installed over range/rangetop with gas char-grill.
** It is recommended that the 1,500 CFM ventilator be used with longer duct runs.
An interior- or exterior-power ventilator kit must be purchased for installation with all Custom Ventilator Systems.
* A 1,200 CFM interior- or exterior-power ventilator should be used when installed over range/rangetop with gas char-grill.
** It is recommended that the 1,500 CFM ventilator be used with longer duct runs.
An interior- or exterior-power ventilator kit must be purchased for installation with all Custom Ventilator Systems.
Built-in custom ventilation systems – Professional
B U I L T - I N C U S T O M V E N T I L A T I O N S Y S T E M S
Model Number
of
Lights
Number
of
Filters Interior Exterior
Recommended Ventilator Kits Recommended
Duct Size
Interior Exterior
Maximum
Amps
Interior Exterior
Built-in custom ventilation systems – Designer
WALL HOODS – 18" DEEP
30" W./12" H. DBCV3082 2 2 DIV300/DIV440* DEV900/DEV1200* 7" 10" 1.7/3.2 6.6/3.9
36" W./14" H. DBCV3682 2 2 DIV300/DIV440* DEV900/DEV1200* 7" 10" 1.7/3.2 6.6/3.9
42" W./14" H. DBCV4282 2 3 DIV440* DEV900/DEV1200* 7" 10" 3.2 6.6/3.9
48" W./14" H. DBCV4882 2 3 DIV880* DEV1200/DEV1500** 10" 10" 5.6 4.3/5.1
ISLAND HOODS – 23" DEEP
36" W./12" H. DICV3632 4 2 DIV440 DEV900/DEV1200 7" 10" 4.0 7.5/5.2
42" W./14" H. DICV4232 4 2 DIV440 DEV900/DEV1200/DEV1500** 7" 10" 4.0 7.5/5.2/6.0
54" W./14" H. DICV5432 4 3 DIV880 DEV1200/DEV1500** 10" 10" 6.4 5.2/6.0
34 35
WALL HOODS – 22" DEEP
30" W. VBCV3038 2 2 1 VIV300/VIV600/VIV1200* VEV900/VEV1200* 7"/10" 10" 5.0/6.7/8.7 8.7/6.1
36" W. VBCV3638 2 2 1 VIV300/VIV600/VIV1200* VEV900/VEV1200* 7"/10" 10" 5.0/6.7/8.7 8.7/6.1
42" W. VBCV4238 2 2 1 VIV600/VIV1200* VEV900/VEV1200* 7"/10" 10" 6.2/8.7 8.7/6.1
48" W. VBCV4838 3 3 2 VIV1200 VEV1200/VEV1500** 10" 10" 11.1 8.7/6.1
54" W. VBCV5438 3 3 2 VIV1200 VEV1200/VEV1500** 10" 10" 11.1 8.7/6.1
60" W. VBCV6038 4 4 2 VIV1200 VEV1200/VEV1500** 10" 10" 11.1 8.8/9.5
66" W. VBCV6638 4 4 2 VIV1200 VEV1200/VEV1500** 10" 10" 11.1 8.8/9.5
ISLAND HOODS – 18" DEEP
36" W. VICV3698 4 4 – VIV600/VIV1200* VEV900/VEV1200* 7" 10" 4.9/7.4 7.4/4.7
42" W. VICV4298 4 4 – VIV600/VIV1200* VEV900/VEV1200*/VEV1500** 7" 10" 4.9/7.4 7.4/4.8/5.4
54" W. VICV5498 6 6 – VIV1200 VEV900/VEV1200*/VEV1500** 7" 10" 8.2 7.4/5.6/6.2
66" W. VICV6698 8 8 – VIV1200 VEV900/VEV1200*/VEV1500** 7" 10" 9.0 7.4/6.3/7.1
Width: 17 1/8" (43.5 cm)
Height: 8 1/16" (20.5 cm)
Depth: 13 13/16" (35.1 cm)
Overall: 1.1 cu. ft.
1.6 kW, 13.2 A
15 5/16" (38.9 cm)
Microwave hood – Professional
VMOR205
Overall Width 29 15/16" (76.1 cm)
Overall Height
Overall Depth
Electrical Requirements
Maximum Amp Usage
Description
M I C R O W A V E H O O D
16 6/16" (41.7 cm)
120 V, single phase, 60 Hz, AC only
Overall Interior
Dimensions
Approximate Shipping
Weight 85 lb. (38.6 kg)
Width: 17 1/8" (43.5 cm)
Height: 8 1/16" (20.5 cm)
Depth: 13 13/16" (35.1 cm)
Overall: 1.1 cu. ft.
1.6 kW, 13.2 A
15 5/16" (38.9 cm)
Microwave hood – Designer
DMOR205
Overall Width 29 15/16" (76.1 cm)
Overall Height
Overall Depth
Electrical Requirements
Maximum Amp Usage
Description
M I C R O W A V E H O O D
16 6/16" (41.7 cm)
120 V, single phase, 60 Hz, AC only
Overall Interior
Dimensions
Approximate Shipping
Weight 85 lb. (38.6 kg)
