Chapter 2: product description, Front of router – VIEWSONIC WR100 User Manual
Page 9
ViewSonic Wireless Router
5
This chapter describes the parts of the router on the Front and Back panels.
Front of router
POWER LED
ON – Blue
WAN LED
Cable or DSL modem
Blinking means data is transferring
WLAN LED
ON – Green
Link/Act LEDs
Blinking LED indicates
an active connection to
Port 1, 2, 3, and/or 4
10 Mbps = OFF
100 Mbps = ON
On LEDs indicate data is
transferring
Antenna
Chapter 2: Product Description
