2007 Volvo V70
pg. 203 Maintenance and servicing
Replacing bulbs
Replacing bulbs in the tail light cluster
All bulbs in the tail light cluster can be replaced from inside the cargo area.
1. Turn signal
2. Brake light
3. Parking light
4. Fog light (left side only)
5. Backup light
To replace a bulb
- Switch off all lights and turn ignition key to position 0.
- Open the access panel.
- Twist the bulb holder counterclockwise and remove it.
- Press the bulb inward, twist it counterclockwise and extract it.
- Fit a new bulb.
- Fit the bulb holder in place and twist it clockwise.
- Refit the sound insulation and put the access panel back in place.
NOTE: If the message indicating a burned out bulb remains in the information display after the bulb has
been replaced, consult an authorized Volvo retailer.
Replacing turn signal and brake light bulbs
- Switch off all lights and turn the ignition switch to position 0.
- Using a screwdriver, carefully pry off the speaker grille.
- Pull out the red tab in the speaker.
- Then press on the black pin above the extracted red tab and twist out the speaker.
