2007 Volvo V70
Spare tire, tool bag, jack - vehicles with subwoofer (option)
The spare tire, jack and tool bag are located under the floor of the cargo space in a compartment in front
of the spare tire. To access the spare tire:
- Remove the rear hinged floor panel by raising it approx. 6 inches (15 cm) and then pulling it rearward
out of the cargo area.
- Raise the other floor panel to upright position and lock it there.
- Remove the mat.
- Loosen the wheel and turn the clip 90°.
- Lift the subwoofer inward-upward with both hands and tilt it leftward.
- Unstrap and lift out the jack and tool bag.
- Unscrew the securing bracket and remove the spare tire from the storage well.
- When putting the tire and subwoofer back into place, perform these steps in reverse order. Make sure
the spare tire, jack, tool bag and subwoofer are properly secured.
WARNING!
Make sure that the spare tire, jack and tool bag are properly secured with the securing bracket and
strap to help keep these components in place in the event of a sudden stop.
pg. 174 Wheels and tires
Changing wheels
