Vertex Standard VX-410 - Manual (Page 33)

33
R 1290 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B e2
R 1291 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B e2
R 1293 CHIP RES. 180k 1/16W 5% RMC1/16S 184JTH J24189052 1- B d1
R 1297 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 W/LCD 1 B d3
R 1297 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 W/LCD 2- B d3
R 1298 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 W/LCD 1 B d3
R 1298 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 W/LCD 2- B d3
R 1299 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B d2
R 1300 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B e2
R 1301 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D2
R 1302 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B e1
R 1303 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e1
R 1304 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1-
S 1002 ROTARY SWITCH TP70TF5161 N0190183 1- B a2
S 1003 TACT SWITCH SKRTLAE010 N5090130 1- B a1
S 1004 TACT SWITCH SKRTLAE010 N5090130 1- B b1
S 1005 TACT SWITCH SKRTLAE010 N5090130 1- B c1
TH1001 THERMISTOR TBPS1R103K440H5Q G9090067 1- A D2
TH1002 THERMISTOR ERTJ0EV473J G9090120 1- A C2
VR1001 POT. TP76N00N 20KA/SW RY-7513 J60800269 1- B a3
X 1001 XTAL SX-1319 7.3728MHz 7.3728MHZ H0103275 1- A C3
X 1002 TCXO 16.8MHz TTS05VS-M1 16.8MHZ H9500830 1- B d2
XF1001 XTAL FILTER MFT50.85P2 50.85MHZ H1102364 1- B b2
LCD HOLDER RA0546600 W/LCD 1-
INTER CONNECTOR RA0546800 W/LCD 1-
TERMINAL PLATE R RA010700A 1-
TERMINAL HOLDER RA010340B 1-
LIGHT GUIDE (LCD) RA0546700 W/LCD 1-
REFLECTOR SHEET RA0546900 W/LCD 1-
SHIELD CASE VCO RA0208100 1-
DESCRIPTION VALUE V/W TOL. VXSTD P/N VERS. REF. LOT. SIDE LAY ADR MFR’S DESIG
MAIN Unit
