Vertex Standard VX-410 - Manual (Page 23)

23
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/N MFR’S DESIG VERS. REF. LOT. SIDE LAY ADR
PCB with Components CB2435001 LCD ON
CB2435002 LCD OFF
Printed Circuit Board FR010220D 1-
C 1002 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1 B a1
C 1002 CHIP CAP. 47pF 50V CH GRM36CH470J50PT K22178228 2- B a1
C 1006 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A E1
C 1007 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D1
C 1008 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A E1
C 1009 CHIP TA.CAP. 2.2uF 6.3V TESVA0J225M1-8R K78080009 1- A D1
C 1011 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A E1
C 1013 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A C1
C 1015 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A E3
C 1016 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A E2
C 1018 AL.ELECTRO.CAP. 220uF 10V EEE1AA221XP K48100007 1- B a2
C 1019 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1- A E2
C 1020 CHIP TA.CAP. 2.2uF 6.3V TESVA0J225M1-8R K78080009 1- A E2
C 1021 CHIP CAP. 27pF 50V CH GRM36CH270J50PT K22178222 1- B a1
C 1022 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B a1
C 1023 CHIP CAP. 1pF 50V CK GRM36CK010C50PT K22178202 1- B a1
C 1024 CHIP CAP. 2pF 50V CK GRM36CK020C50PT K22178204 1- B a1
C 1025 CHIP CAP. 3pF 50V CJ GRM36CJ030C50PT K22178205 1- B a1
C 1027 CHIP CAP. 3pF 50V CJ GRM36CJ030C50PT K22178205 1- B a1
C 1028 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a1
C 1029 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 1- B a1
C 1030 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 1- B a1
C 1031 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a1
C 1032 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 1- B b1
C 1033 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 1- B a1
C 1035 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A E1
C 1036 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A E1
C 1037 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E1
C 1038 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B b1
C 1039 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B b1
C 1041 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C1
C 1042 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C1
C 1043 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A C1
C 1044 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B e1
C 1045 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- A C1
C 1046 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B e1
C 1047 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1- A D3
C 1048 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- A D3
C 1050 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1- A D2
C 1052 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A E2
C 1054 CHIP TA.CAP. 22uF 16V TEMSVB21C226M-8R K78120028 1- A E2
C 1055 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- A E2
C 1057 CHIP CAP. 4pF 50V CH GRM36CH040C50PT K22178206 1- B a1
C 1059 CHIP CAP. 3pF 50V CJ GRM36CJ030C50PT K22178205 1- B a2
C 1060 CHIP CAP. 100pF 50V CH GRM36CH101J50PT K22178236 1- B a1
C 1061 CHIP CAP. 18pF 50V CH GRM36CH180J50PT K22178218 1 B b1
C 1061 CHIP CAP. 27pF 50V CH GRM36CH270J50PT K22178222 2- B b1
C 1062 CHIP TA.CAP. 10uF 16V TEMSVB21C106M-8R K78120025 1- B b1
C 1063 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b1
C 1065 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B b1
C 1066 CHIP CAP. 15pF 50V CH GRM36CH150J50PT K22178216 1- B b1
C 1068 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b1
C 1071 CHIP TA.CAP. 0.1uF 35V TESVA1V104M1-8R K78160025 1- B d1
C 1072 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A D1
C 1073 CHIP CAP. 1uF 10V B ECJ2FB1A105K K22100806 1- B d1
C 1074 CHIP TA.CAP. 4.7uF 16V TEMSVA1C475M-8R K78120031 1- B d3
C 1075 CHIP TA.CAP. 2.2uF 6.3V TESVA0J225M1-8R K78080009 1- B d3
C 1076 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d3
C 1077 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d3
C 1078 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B d2
C 1079 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d3
C 1080 CHIP TA.CAP. 2.2uF 6.3V TESVA0J225M1-8R K78080009 1- B d3
C 1081 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 1- B d2
C 1082 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B d3
MAIN Unit
