Main unit – Vertex Standard VX-410 User Manual
Page 31
31
DESCRIPTION
VALUE
V/W
TOL.
VXSTD P/N
MFR’S DESIG
VERS.
REF.
LOT. SIDE LAY ADR
R 1154
CHIP RES.
100k
1/16W
5%
RMC1/16S 104JTH
J24189049
1-
B
c2
R 1155
CHIP RES.
150
1/16W
5%
RMC1/16S 151JTH
J24189015
1-
B
c2
R 1157
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
B
b2
R 1158
CHIP RES.
100
1/16W
5%
RMC1/16S 101JTH
J24189013
1-
B
b2
R 1159
CHIP RES.
560
1/16W
5%
RMC1/16S 561JTH
J24189022
1-
B
b2
R 1160
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
B
b2
R 1161
CHIP RES.
270
1/16W
5%
RMC1/16S 271JTH
J24189018
1-
B
c1
R 1162
CHIP RES.
220
1/16W
5%
RMC1/16S 221JTH
J24189017
1-
B
c2
R 1163
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
B
b1
R 1164
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
B
c2
R 1165
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
W/LCD
1-
A
C3
R 1166
CHIP RES.
47
1/16W
5%
RMC1/16S 470JTH
J24189009
W/LCD
1
B
d3
R 1166
CHIP RES.
180
1/16W
5%
RMC1/16S 181JTH
J24189016
W/LCD
2-
B
d3
R 1167
CHIP RES.
47
1/16W
5%
RMC1/16S 470JTH
J24189009
W/LCD
1
B
d3
R 1167
CHIP RES.
180
1/16W
5%
RMC1/16S 181JTH
J24189016
W/LCD
2-
B
d3
R 1168
CHIP RES.
100
1/16W
5%
RMC1/16S 101JTH
J24189013
1-
A
D3
R 1169
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
B
e2
R 1170
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
B
e2
R 1171
CHIP RES.
470k
1/16W
5%
RMC1/16S 474JTH
J24189057
1-
A
D2
R 1172
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
B
e1
R 1173
CHIP RES.
47k
1/16W
5%
RMC1/16S 473JTH
J24189045
1-
A
D3
R 1174
CHIP RES.
6.8k
1/16W
5%
RMC1/16S 682JTH
J24189035
1-
A
D3
R 1175
CHIP RES.
15k
1/16W
5%
RMC1/16S 153JTH
J24189039
1-
A
D3
R 1176
CHIP RES.
22
1/16W
5%
RMC1/16S 220JTH
J24189005
1-
B
b2
R 1177
CHIP RES.
390
1/16W
5%
RMC1/16S 391JTH
J24189020
1-
B
b2
R 1178
CHIP RES.
47k
1/16W
5%
RMC1/16S 473JTH
J24189045
1-
B
b2
R 1179
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
B
b3
R 1180
CHIP RES.
10
1/16W
5%
RMC1/16S 100JTH
J24189001
1-
B
b2
R 1181
CHIP RES.
10
1/16W
5%
RMC1/16S 100JTH
J24189001
1-
B
b2
R 1182
CHIP RES.
5.6k
1/16W
5%
RMC1/16S 562JTH
J24189034
1-
B
c2
R 1182
CHIP RES.
3.3k
1/16W
5%
RMC1/16S 332JTH
J24189031
3-
B
c2
R 1184
CHIP RES.
2.7k
1/16W
5%
RMC1/16S 272JTH
J24189030
1-
B
d2
R 1184
CHIP RES.
2.2k
1/16W
5%
RMC1/16S 222JTH
J24189029
3-
B
d2
R 1185
CHIP RES.
2.7k
1/16W
5%
RMC1/16S 272JTH
J24189030
1-
B
d2
R 1185
CHIP RES.
2.2k
1/16W
5%
RMC1/16S 222JTH
J24189029
3-
B
d2
R 1186
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
B
d2
R 1188
CHIP RES.
33
1/16W
5%
RMC1/16S 330JTH
J24189007
1-
B
d1
R 1189
CHIP RES.
33
1/16W
5%
RMC1/16S 330JTH
J24189007
1-
B
d1
R 1190
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
E1
R 1191
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
W/LCD
1-
A
C3
R 1192
CHIP RES.
330
1/16W
5%
RMC1/16S 331JTH
J24189019
1-
A
E1
R 1193
CHIP RES.
150
1/16W
5%
RMC1/16S 151JTH
J24189015
1-
A
E1
R 1194
CHIP RES.
10k
1/16W
5%
RMC1/16S 103JTH
J24189037
1-
A
D3
R 1195
CHIP RES.
47k
1/16W
5%
RMC1/16S 473JTH
J24189045
1-
A
D2
R 1196
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1197
CHIP RES.
47
1/16W
5%
RMC1/16S 470JTH
J24189009
W/LCD
1
A
C3
R 1197
CHIP RES.
100
1/16W
5%
RMC1/16S 101JTH
J24189013
W/LCD
2-
A
C3
R 1198
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1199
CHIP RES.
0
1/16W
5%
RMC1/16S JPTH
J24189070
1-
B
e1
R 1200
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1201
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1202
CHIP RES.
22k
1/16W
5%
RMC1/16S 223JTH
J24189041
1-
A
D2
R 1203
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1204
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1205
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1206
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1207
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1208
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1209
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1210
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1211
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1212
CHIP RES.
470
1/16W
5%
RMC1/16S 471JTH
J24189021
1-
A
C3
R 1214
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1215
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1216
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1217
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D2
R 1218
CHIP RES.
1k
1/16W
5%
RMC1/16S 102JTH
J24189025
1-
A
D1
MAIN Unit
