DESCRIPTION
VALUE
V/W
TOL.
VXSTD P/N
MFR’S DESIG
VERS.
REF.
LOT. SIDE LAY ADR
C 1241
CHIP CAP.
0.001uF
50V
B
GRM36B102K50PT
K22178809
1-
A
D3
C 1242
CHIP CAP.
0.01uF
16V
B
GRM36B103K16PT
K22128804
1-
A
D3
C 1243
CHIP CAP.
0.001uF
50V
B
GRM36B102K50PT
K22178809
1-
B
b2
C 1244
CHIP CAP.
0.001uF
50V
B
GRM36B102K50PT
K22178809
1-
B
b2
C 1245
CHIP CAP.
0.047uF
10V
B
GRM36B473K10PT
K22108801
1-
B
c2
C 1246
CHIP CAP.
0.1uF
10V
B
GRM36B104K10PT
K22108802
1-
B
c2
C 1248
CHIP CAP.
0.1uF
10V
B
GRM36B104K10PT
K22108802
1-
B
d2
C 1250
CHIP CAP.
0.001uF
50V
B
GRM36B102K50PT
K22178809
1-
B
c2
C 1251
CHIP CAP.
82pF
50V
CH
GRM36CH820J50PT
K22178234
1-
B
c2
C 1252
CHIP CAP.
0.1uF
10V
B
GRM36B104K10PT
K22108802
1-
B
c3
C 1256
CHIP CAP.
100pF
50V
CH
GRM36CH101J50PT
K22178236
1-
B
d1
C 1257
CHIP CAP.
27pF
50V
CH
GRM36CH270J50PT
K22178222
1-
B
d2
C 1259
CHIP CAP.
0.01uF
16V
B
GRM36B103K16PT
K22128804
1-
B
d2
C 1260
CHIP CAP.
0.01uF
16V
B
GRM36B103K16PT
K22128804
1-
B
d2
C 1261
CHIP CAP.
0.001uF
50V
B
GRM36B102K50PT
K22178809
1-
B
d2
C 1262
CHIP CAP.
82pF
50V
CH
GRM36CH820J50PT
K22178234
1-
B
c2
C 1263
CHIP CAP.
5pF
50V
CH
GRM36CH050C50PT
K22178207
1-
B
d2
C 1264
CHIP CAP.
0.0047uF
25V
B
GRM36B472K25PT
K22148830
1-
B
d2
C 1265
CHIP CAP.
0.1uF
10V
B
GRM36B104K10PT
K22108802
1-
B
d3
C 1266
CHIP CAP.
0.1uF
10V
B
GRM36B104K10PT
K22108802
1-
B
c3
C 1267
CHIP CAP.
220pF
50V
B
GRM36B221K50PT
K22178801
1-
B
c3
C 1268
CHIP CAP.
220pF
50V
B
GRM36B221K50PT
K22178801
1-
B
c3
C 1269
CHIP CAP.
0.01uF
16V
B
GRM36B103K16PT
K22128804
1-
B
c3
C 1270
CHIP CAP.
0.001uF
50V
B
GRM36B102K50PT
K22178809
1-
B
e2
C 1271
CHIP CAP.
100pF
50V
CH
GRM36CH101J50PT
K22178236
1-
B
c1
C 1273
CHIP CAP.
100pF
50V
CH
GRM36CH101J50PT
K22178236
1-
B
c1
C 1274
CHIP CAP.
0.01uF
16V
B
GRM36B103K16PT
K22128804
1-
B
d2
C 1275
CHIP CAP.
100pF
50V
CH
GRM36CH101J50PT
K22178236
1-
B
d1
C 1276
CHIP CAP.
0.1uF
10V
B
GRM36B104K10PT
K22108802
1-
B
c3
C 1278
CHIP CAP.
0.1uF
10V
B
GRM36B104K10PT
K22108802
1-
A
C1
C 1279
CHIP TA.CAP.
10uF
6.3V
TEMSVA0J106M-8R
K78080027
1-
B
c2
C 1280
CHIP CAP.
0.1uF
10V
B
GRM36B104K10PT
K22108802
1-
B
c2
C 1281
CHIP CAP.
0.1uF
10V
B
GRM36B104K10PT
K22108802
1-
B
d3
C 1283
CHIP TA.CAP.
4.7uF
16V
TEMSVA1C475M-8R
K78120031
1-
B
e2
CD1001 CERAMIC DISC
ECDA450C24
H7901460
1-
B
c2
CF1001 CERAMIC FILTER
ELFC450G
H3900538
1-
B
c3
CF1002 CERAMIC FILTER
ELFY450E
H3900549
1-
B
b3
D 1001
DIODE
1SS400G T2R
G2070934
1-
A
C1
D 1002
DIODE
1SS400G T2R
G2070934
1-
A
C1
D 1004
DIODE
RLS135 TE-11
G2070128
1-
B
a1
D 1005
DIODE
HSU277TRF
G2070118
1-
B
a1
D 1006
DIODE
HSU277TRF
G2070118
1-
B
a1
D 1007
DIODE
HVD350B
G2070946
1-
B
a2
D 1008
DIODE
HVD350B
G2070946
1-
B
a2
D 1009
DIODE
HVD350B
G2070946
1-
B
a2
D 1010
DIODE
HVD350B
G2070946
1-
B
a2
D 1012
DIODE
HVD350B
G2070946
1-
B
a2
D 1013
DIODE
HVD350B
G2070946
1-
B
a2
D 1014
DIODE
HSC277TRF
G2070584
1-
B
c2
D 1015
DIODE
1SS400G T2R
G2070934
1-
B
b2
D 1016
DIODE
HVD350B
G2070946
1-
B
a3
D 1017
DIODE
HVD350B
G2070946
1-
B
c2
D 1018
DIODE
1SS400G T2R
G2070934
1-
A
E2
D 1019
DIODE
1SS400G T2R
G2070934
1-
B
e2
D 1020
DIODE
DA221 TL
G2070178
1-
A
D3
D 1021
DIODE
HVD350B
G2070946
1-
B
b2
D 1022
DIODE
HVD350B
G2070946
1-
B
b2
D 1023
DIODE
HVD350B
G2070946
1-
B
b1
D 1024
DIODE
HVD350B
G2070946
1-
B
b1
D 1025
DIODE
1SS400G T2R
G2070934
1-
A
E1
D 1026
DIODE
1SS400G T2R
G2070934
1-
A
E1
D 1027
LED
LNJ808K8SRA
G2070790
W/LCD
1-
A
B1
D 1028
LED
LNJ808K8SRA
G2070790
W/LCD
1-
A
A1
D 1029
LED
LNJ808K8SRA
G2070790
W/LCD
1-
A
B2
D 1030
LED
LNJ808K8SRA
G2070790
W/LCD
1-
A
A2
D 1031
DIODE
1SS400G T2R
G2070934
1-
B
e2
D 1032
DIODE
1SS400G T2R
G2070934
1-
B
e2
