VIVOTEK
User's Manual - 99
endtime hh:mm 6/6 End time of the weekly schedule.
(00:00~24:00 indicates schedule always on)
prefix string[16] 6/6 Indicate the prefix of the filename.
cyclesize 6/6 The maximum size for cycle recording in Kbytes
when choosing to limit recording size.
maxfilesize 200~6000 6/6 The max size for one file in Kbytes
dest 0~4 6/6 The destination to store the recorded data.
“0~4” means the index of the network storage.
Group: path
NAME VALUE SECURITY
(get/set)
DESCRIPTION
encoder1_start 7/7 Specify the HTTP push server is active for stream 1
encoder2_start 7/7 Specify the HTTP push server is active for stream 2
Drive the Digital Output
Note: This request requires Viewer privileges.
Method: GET/POST
Syntax:
http://<servername>/cgi-bin/dido/setdo.cgi?do1=[&do2=]
[&do3=][&do4=][&return=]
Where state is 0 or 1; “0” means inactive or normal state, while “1” means active or triggered state.
PARAMETER VALUE DESCRIPTION
0 – Inactive, normal state do 0, 1
1 – Active, triggered state
return Redirect to the page after the parameter is assigned. The
can be a full URL path or relative path according to the
current path. If you omit this parameter, it will redirect to an empty page.
Example: Drive the digital output 1 to triggered state and redirect to an empty page.
http://myserver/cgi-bin/dido/setdo.cgi?do1=1
